Descrizione
Acoustical operating principle
pressure gradient transducer, permanently polarized
Transducer Ø
17 mm 0,67 inch
Directional pattern
cardioid
Frequency range
20 … 20.000 Hz
Sensitivity
8 mV / Pa (-42 dBV)
Signal / noise ratio
78 dB-A
Equivalent noise level
16 dB-A, cardioid (IEC 61672-1)
Dynamic range of mic. amp.
130 dB-A
Max. SPL for 0,5 % THD
146 dB, 0 dB pre-attenuation 156 dB, 10 dB pre-attenuation 166 dB, 20 dB pre-attenuation
Pre-attenuation pad
10 dB, 20 dB, switchable
Bass cut filter slope
12 dB / octave at 40 Hz 6 dB / octave at 300 Hz
Rated impedance
1.000 ohms
Supply voltage
48 V + / – 4 V (IEC 61938)
Current consumption
4,7 mA (IEC 61938)
Connector
gold plated 3-pin XLR
Dimensions
138 x 52 x 36 mm 5,43 x 2,04 x 1,42 inch
Net weight
310 g 10,9 oz
2/3-inch small-diaphragm capsule with ultra-thin externally biased, gold-layered low mass diaphragm for powerful and neutral sound reproduction
Neutral frequency response for authentic sound onstage or in the studio
Cardioid polar pattern for effective isolation of the main sound source
Low self-noise and a total dynamic range of 130 dB provides an outstanding acoustic presence and powerful yet authentic sound
3-position switchable pre-attenuation pad (0 dB, 10 dB, and 20 dB) for handling extremely high sound pressure levels and 3-position high-pass filter
Illuminated user interface for quick and easy handling even in dark environments
Noiseless pushbuttons for quick and easy attenuation and high-pass filter selection
Clipping history, automatic attenuation and key-lock provide error-free recording and unparalleled ease of use
Rugged black all-metal construction for durable performance onstage and in the studio
Extra-large hexagonal ruthenium-galvanized steel mesh grille provides an open acoustic environment and prevents unwanted internal reflections
Immune to electromagnetic interference thanks to transformerless preamplifier circuitry
Corrosion-resistant gold-plated 3-pin XLR output connector
Comes in a cardboard box with foam layers; includes DTP 40 Mts shock mount, LCT 40 Wx windshield and DTP 40 Lb artificial leather bag
