Descrizione
Features and Applications
Features
Proprietary dynamic capsule tuned specifically for demanding vocal applications, with brightened range and extended low end
Uniform supercardioid pickup pattern for maximum isolation of the main sound source
Optional active mode provides superior dynamic range of 121 dB-A and extremely low self-noise of 19 dB-A for ear-catching realism and distortion-free sonic depth
Optional 3-position switchable amplification (0 dB, 6 dB, and 12 dB) for unrivalled signal quality in demanding environments
3-position switchable high-pass filter for direct adjustment of proximity effect according to application and artist
Illuminated indication of microphone settings for quick and easy handling even in dark environments
Recessed slide switches prevent unintended change of settings
Effective integrated acoustic pop and windshield offers excellent protection without compromising high-frequency clarity
Rock-solid full metal, die-cast body for rough daily touring routine
Hardened steel mesh grille to prevent wear and abuse
Minimally affected by varying load impedance
Corrosion-resistant gold-plated 3-pin XLR output connector
Comes in a cardboard box including MTP 40 MCs shock mount and DTP 40 Lb artificial leather bag
Top applications
Lead and background vocals
Demanding live and studio applications
Tech Data
Acoustical operating principle
Dynamic, moving coil
Directional pattern
Super-cardioid
Frequency range
40 to 18.000 Hz
Sensitivity
3,5 mV / Pa (-49 dBV), passive mode7 mV / Pa (-43 dBV), active mode14 mV / Pa (-37 dBV), active mode
Signal / noise ratio
75 dB-A
Equivalent noise level
19 dB-A, Super-cardioid (IEC 61672-1)
Dynamic range, passive mode
135 dB-A
Dynamic range, active mode
121 dB-A，0 dB gain115 dB-A，6 dB gain109 dB-A，12 dB gain
Max. SPL for 0,5 % THD, active mode
140 dB, 0 dB gain134 dB, 6 dB gain128 dB, 12 dB gain
Gain settings, active mode
0 dB, 6 dB, 12 dB, switchable
Bass cut filter slope
12 dB / octave at 150 Hz12 dB / octave at 250 Hz
Rated impedance
1.000 ohms
Supply voltage
48 V +/- 4 V (IEC 61938)
Current consumption
5,5 mA (IEC 61938)
Connector
Gold plated 3-pin XLR
Dimensions
51 dia. x 183 mm2 dia. x 7,2 inch
Net weight
336 g 11.85 oz
