Descrizione

Features and Applications
Features

1-inch externally biased, dual-system capsule with ultra-thin, gold-layered low-mass diaphragms ensure accurate transient response for nuanced and authentic sound
Flat frequency response for natural sound
Three consistent directional characteristics – cardioid, wide cardioid, supercardioid – for maximum flexibility in a variety of live and recording applications
Superior dynamic range of 135 dB-A and exceptionally low self-noise of 9 dB-A thanks to innovative direct coupling technology (patent pending) for ear-catching realism and distortion-free sonic depth
3-position switchable pre-attenuation pad (0 dB, 6 dB, and 12 dB) for handling extremely high sound pressure levels
3-position switchable high-pass filter for direct adjustment of proximity effect according to application and artist
Illuminated indication of microphone settings for quick and easy handling even in dark environments
Recessed slide switches prevent unintended change of settings
Effective integrated acoustic pop and windshield offers excellent protection without compromising high-frequency clarity
Rock-solid full-metal, die-cast body for rough daily touring routine
Hardened steel mesh grille to prevent wear and abuse
Minimally affected by varying load impedance
Corrosion-resistant gold-plated 3-pin XLR output connector
Comes in a cardboard box including MTP 40 MCs shock mount and DTP 40 Lb artificial leather bag

Top applications

Lead and background vocals
Demanding live and studio applications

Tech Data

Acoustical operating principle
Pressure gradient transducer,externally polarized

Transducer Ø
25,4 mm1 inch

Directional pattern
Wide cardioidCardioidSuper-cardioid

Frequency range
20 to 20.000 Hz

Sensitivity
10 mV / Pa (-40 dBV), cardioid

Signal / noise ratio
85 dB-A

Equivalent noise level
9 dB-A, cardioid (IEC 61672-1)

Dynamic range of mic. amp.
135 dB-A

Max. SPL for 0,5 % THD
144 dB, 0 dB pre-attenuation150 dB, 6 dB pre-attenuation156 dB, 12 dB pre-attenuation

Pre-attenuation pad
6 dB, 12 dB, switchable

Bass cut filter slope
12 dB / octave at 80 Hz12 dB / octave at 160 Hz

Rated impedance
1.000 ohms

Supply voltage
48 V +/- 4 V (IEC 61938)

Current consumption
5,5 mA (IEC 61938)

Connector
Gold plated 3-pin XLR

Dimension
51 dia. x 183 mm2 dia. x 7,2 inch

Net weight
332 g11.71 oz
