Descrizione

Features

18 MIC/LINE inputs, 4 STEREO inputs
8 single-control dynamic compressors (Ch. 1-Ch.8)
4 STEREO AUX returns
3-band EQ with sweepable MID Frequency on microphone channels
4-band fixed EQ on stereo line channels
4 AUX sends per channel: 2 PRE/POST faders switchable
4-GROUP MIX
24-bit DSP effects for 99 presets
USB port for PC audio recording and playback

Electronic Specs.

Frequency Response: 20Hz ÷ 20kHz
Total Harmonic Distortion (THD+N): 0,03%%

Inputs

Mic: 18
Gain range: 0dB ÷ -50dB
Low Cut: 75Hz
Phantom Power +48V: Yes
Mono Line: 16
Gain range: 20dB ÷ -30dB
Stereo Line: 4
2 Track: Yes
Stereo Return: 4

Outputs

Main MIX: 1
Control Room: 1
AUX Send: 4
FX Send: 1
Group Out: 4
Phones: 2
2 Track: Yes

Compressors

Single Control: 8

EQ

BANDS on MONO channels: 3
  Sweepable mid frequency 100Hz-8kHz
BANDS on STEREO channels: 4
  +/-15dB @ 12kHz – Shelving, +/-15dB @ 3kHz, +/-15dB @ 500Hz, +/-15dB @ 80Hz – Shelving

Auxiliary Sends

AUX: 2 PRE/POST
AUX: 1 + 1 FX POST
FX: 1 POST

Internal Effects

Height: 99

Usb Audio

Play trk: 2
Rec trk: 2

Other Features

Optional Card Slot: Yes
Footswitch: Yes

Electrical Specs.

Power supply: Internal
Power requirements: 100-240V
Power consumption: 70W

Cabinet

Cabinet Material: Metal
Colour: Black

Phisical Specification

Height: 85/3.34 mm/inch
Width: 735/28.93 mm/inch
Depth: 460/18.11 mm/inch
Net Weight: 9.67/21.31 Kg/Lbs

I dati riportati sono indicativi e non vincolanti; RCF si riserva la facoltà di effettuare eventuali modifiche in qualsiasi momento e senza preavviso.
