Descrizione

TOPP PRO FLX3 SYSTEM SISTEMA AMPLIFICATO 600W FORMATO DA  2 FLX 3 + SUBWOOFER S12FLX
DESCRIZIONE
Sistema mini-array n°2 FLX3+ n°1 subwoofer Soho S12FLX
SPECIFICHE

Model
FLX 3

System Type
3″ 2-way Passive System

Output Power
40W (CONTINUOUS) , 80W (PROGRAM)

Sensitivity (1W/1M)
90dB

Maximum SPL @ 1m
106dB Max. (calculated)

Frequency Response
100Hz-20kHz (-10dB)

Impedance
8 ohms

Transducer Low
2 x 3” Woofer, 0.75” (19mm) Voice Coil

Transducer High
3 x Ø13mm Voice Coil Neodymium Tweeter

Crossover Frequency
2.5kHz

Dispersion(-6dB)
100° Horizontal, 30° Vertical (one module)

Attachment Points
Adjustable Rigging System, Vertical Splay Adjustable in 1.5° Increments from 0°- 12°

Connectors
Parallel or Series Ø6.3mm Socket / Selection Switch

Enclosure Construction
Polypropylene Enclosure, steel Metal Grille with foam

Fittings information
Steel Stirrup Material, 3 Flying Points

Dimensions (HxWxD)
(W) 265mm x (H) 124mm x (D) 195mm; (W) 10.43″ x (H) 4.88″ x (D) 7.68″

Net Weight
3.2kg / 7.05 lbs

Model
SOHO S12FLX

Subwoofer
1 x 12″

Frequency response -6 dB
40 Hz – 500 Hz

Amplifier, subwoofer
1 x 350W / Class D @ 4 Ohms

Amplifier, satellite/ mid/ high unit
1 x 350W / Class D @ 4 Ohms

Axial sensitivity 1W@1m
Axial sensitivity 1W@1m : 96dB

Electronic Protections
Thermal / DC / Overload / Digital Lim./Compressor

Cooling
Temperature-controlled fan

Connections
2 Combo-XLR 1/4” In, 1 XLR In, 1 RCA In L&R, 1 XLR Thru, 1 Speakon Out

External Controls
Volume Control / Switch for Input sens / Swtich for mode selector / Power ON with Green LED / Limiter with Red LED / USB (Customer Sound)

Power Supply
115V/230V Switchable

Enclosure Construction
Plywood cabinet, resistant black paint, metal grille with foam, rubber feet, handles

Mounting
one metal standard pole-mount
