Specifiche
Outline

Mixing capabilityOn-board processors
SPX algorithm: 6 programs

I/OPhantom power
+48 V

Input ChannelsMono[MIC/LINE]
2

Stereo[LINE]
2

Output ChannelsSTEREO OUT
2

PHONES
1

Bus
Stereo: 1

Input Channel FunctionPAD
26 dB (Mono)

HPF
80 Hz, 12 dB/oct (Mono)

EQ HIGH
(Mono) Gain: +15 dB/-15 dB, Frequency: 10 kHz shelving

EQ LOW
(Mono) Gain: +15 dB/-15 dB, Frequency: 100 Hz shelving

PEAK LED
LED turns on when post EQ signal reaches 3 dB below clipping

Level Meter
2 x 7 -segment LED meter [PEAK, +6, +3, 0, -3, -10, -20 dB]

General specifications

Total harmonic distortion
0.01 % @ +8dBu (20 Hz to 20kHz), GAIN knob: Min, 0.003 % @ +18dBu (1kHz), GAIN knob: Min

Frequency response
+0.5 dB/-0.5 dB (20 Hz to 20 kHz) , refer to the nominal output level @ 1 kHz, GAIN knob: Min

Hum & noise levelEquivalent input noise
-128 dBu (Mono Input Channel, Rs: 150Ω, GAIN knob: Max)

Residual output noise
-102 dBu (STEREO OUT, STEREO LEVEL knob: Min)

Crosstalk
-88 dB

Power requirements
PA-130 (DC12 V/1.0 A, Cable length = 1.8 m), 120 V, 60 Hz, MU18 (DC12 V/1.5 A, Cable length = 1.5 m), 100 V-240 V, 50 Hz/60 Hz or equivalent recommended by Yamaha

Power consumption
12 W

DimensionsW
149 mm (5.9″)

H
62 mm (2.4″)

D
202 mm (7.9″)

Net weight
0.9 kg (1.98 lbs.)

Accessories
Included Accessory: AC Adaptor, Owner’s Manual, Technical Specifications, Optional Accessory: Mic Stand Adaptor BMS-10A

Others
Operating Temperature: 0 to +40˚C
