Mixing capabilityOn-board processors
SPX algorithm: 24 programs

I/OPhantom power
+48 V

Digital I/O
USB Audio Class 2.0 compliant, Sampling Frequency: Max 192 kHz, Bit Depth: 24-bit

Input ChannelsMono[MIC/LINE]
4

Stereo[LINE]
3

Output ChannelsSTEREO OUT
2

MONITOR OUT
1

PHONES
1

AUX SEND
1

Bus
Stereo: 1, AUX[FX]: 1

Input Channel FunctionPAD
26 dB (Mono)

HPF
80 Hz, 12 dB/oct (Mono)

COMP
1-knob compressor Threshold: +22 dBu to -8 dBu, Ratio: 1:1 to 4:1, Output level: 0 dB to 7 dB, Attack time: approx. 25 msec, Release time: approx. 300 msec

EQ HIGH
Gain: +15 dB/-15 dB, Frequency: 10 kHz shelving

EQ MID
Gain: +15 dB/-15 dB, Frequency: 2.5kHz peaking

EQ LOW
Gain: +15 dB/-15 dB, Frequency: 100 Hz shelving

PEAK LED
LED turns on when post EQ signal reaches 3 dB below clipping

Level Meter
2 x 7 -segment LED meter [PEAK, +10, +6, 0, -6, -10, -20 dB]

General specifications

Total harmonic distortion
0.02 % @ +14dBu (20 Hz to 20kHz), GAIN knob: Min, 0.003 % @ +24dBu (1kHz), GAIN knob: Min

Frequency response
+0.5 dB/-1.0 dB (20 Hz to 48 kHz) , refer to the nominal output level @ 1 kHz, GAIN knob: Min

Hum & noise levelEquivalent input noise
-128 dBu (Mono Input Channel, Rs: 150Ω, GAIN knob: Max)

Residual output noise
-102 dBu (STEREO OUT, STEREO LEVEL knob: Min)

Crosstalk
-83 dB

Power requirements
PA-10 (AC 38 VCT, 0.62A, Cable length = 3.6 m) or equivalent recommended by Yamaha

Power consumption
22.9 W

DimensionsW
244 mm (9.6″)

H
71 mm (2.8″)

D
294 mm (11.6″)

Net weight
2.1 kg (4.63 lbs.)

Accessories
Included Accessory: AC Adaptor, Owner’s Manual, Cubase AI Download Information, Technical Specifications, Optional Accessory: Mic Stand Adaptor BMS-10A, Foot Switch FC5

Others
Operating Temperature: 0 to +40˚C
